Superwinch S5500 (SR) Winch - 1455201 - 1455200

Superwinch S5500 Winch – 5,500 lb Capacity

The Superwinch S5500 is engineered for heavy-duty trailer and utility applications, offering a robust 5,500 lb pulling capacity. Powered by a 3.6 HP permanent magnet motor and featuring a 3-stage planetary gear system with a 159:1 ratio, this winch ensures efficient and reliable performance.

Available in two configurations:

• Steel Wire Rope Version (Part #1455200): Equipped with a 9/32 in x 60 ft steel wire rope, ideal for rugged environments.

• Synthetic Rope Version (Part #1455201): Features a 1/4 in x 60 ft synthetic rope, offering lightweight and easy handling.

Both versions include a stainless steel 2-way roller fairlead and a 30 ft wired remote control, allowing for convenient operation from a distance. The mechanical, automatic load-holding brake enhances safety during use.

🔧 Key Features:

• Capacity: 5,500 lbs

• Motor: 3.6 HP permanent magnet motor

• Gear Ratio: 3-stage planetary gearing with 159:1 ratio

• Rope Options:

  • Steel Wire Rope: 9/32 in x 60 ft

  • Synthetic Rope: 1/4 in x 60 ft

• Remote: 30 ft wired remote control

• Fairlead: Stainless steel 2-way roller fairlead

• Brake System: Mechanical, automatic load-holding brake

• Voltage: 12V DC

• Weight:

  • Steel Rope Version: Approximately 56 lbs

  • Synthetic Rope Version: Approximately 40 lbs

Designed with durability and user convenience in mind, the Superwinch S5500 is a dependable choice for those requiring consistent performance in demanding situations.
